vs
8.9Display5.8
8.6Health tracking5.0
6.4Sports & outdoor8.0
7.9Smart features3.9
7.7Build & durability5.0
Dimensions
Size comparison
Watch Series 10Watch 5 Ultra
| Watch Series 10 | Watch 5 Ultra | Difference | |
|---|---|---|---|
| Height | 46 mm | 46.3 mm | −0.3 mm |
| Width | 39 mm | 46.3 mm | −7.3 mm |
| Thickness | 9.7 mm | 11.4 mm | −1.7 mm |
| Weight | 34 g | 52 g | −17 g |
Drawn to the same scale from the official dimensions (front and side).
Why is Watch Series 10 better than Watch 5 Ultra?
- NFC paymentsYes · Watch 5 Ultra: No
- LTE (cellular)Yes · Watch 5 Ultra: No
- Weight34.4 g vs 51.8 g+51%
- Storage64 GB vs 8 GB8×
- Screen size1.96″ vs 1.5″+31%
- eSIMYes · Watch 5 Ultra: No
- Thickness9.7 mm vs 11.4 mm+18%
- Pixel density330 ppi vs 310 ppi+6%
Why is Watch 5 Ultra better than Watch Series 10?
- Battery capacity327 mAh vs 480 mAh+47%
- Resolution (width)416 px vs 466 px+12%
Specifications
Side by side
| Design & durability | ||
| Case size | 46 mm | 46 mm |
| Weight | 34.4 g | 51.8 g |
| Thickness | 9.7 mm | 11.4 mm |
| Height | 46 mm | 46.3 mm |
| Width | 39 mm | 46.3 mm |
| Case material | Titanium | — |
| Sapphire crystal | Yes | Yes |
| Lens / cover glass | Sapphire crystal glass | Sapphire Glass |
| Water resistance | 5 ATM | 5 ATM |
| Ingress protection | IP6X | IP68 |
| Water resistance (IPx) | — | IPx8 |
| Water rating (maker) | 50 m / 5 ATM | — |
| Colours | Slate, Gold, Natural | Black, Brown |
| Display | ||
| Screen size | 1.96″ | 1.5″ |
| Display technology | OLED | AMOLED |
| Panel | Retina LTPO3 OLED | LTPO AMOLED |
| AMOLED / OLED display | Yes | Yes |
| Always-on display | Yes | — |
| Resolution (width) | 416 px | 466 px |
| Resolution (height) | 496 px | 466 px |
| Pixel density | 330 ppi | 310 ppi |
| Peak brightness | 2,000 nits | — |
| LTPO display | Yes | Yes |
| Refresh rate | 60 Hz | 60 Hz |
| Battery | ||
| Battery life (smartwatch mode) | 0.8 days | — |
| Battery life (hours) | 18 h | — |
| Battery capacity | 327 mAh | 480 mAh |
| Battery type | Li-Ion | — |
| Wireless charging | Yes | — |
| Charged in 30 min | 80% | — |
| Health sensors | ||
| Optical heart rate | Yes | Yes |
| Blood oxygen (SpO2) | Yes | Yes |
| ECG | Yes | Yes |
| Skin temperature | Yes | — |
| Temperature sensor | Yes | — |
| Sleep tracking | Yes | — |
| Sensors | Accelerometer, gyro, heart rate, barometer, always-on altimeter, compass, SpO2, VO2max, temperature (body), temperature (water) | Accelerometer, gyro, heart rate, barometer, compass, SpO2 |
| Sports & navigation | ||
| Built-in GPS | Yes | Yes |
| Satellite systems | GLONASS, GALILEO, BDS, QZSS | — |
| Barometric altimeter | Yes | Yes |
| Compass | Yes | Yes |
| Multisport / triathlon mode | Yes | — |
| Connectivity | ||
| NFC payments | Yes | No |
| LTE (cellular) | Yes | No |
| eSIM | Yes | No |
| Wi-Fi | Wi-Fi 4 | — |
| Bluetooth | 5.3 | 5.2 |
| Ultra Wideband | Yes | — |
| Smart features | ||
| Calls from the wrist | Yes | — |
| Speaker | Yes | Yes |
| Microphone | Yes | — |
| Voice assistant | Yes | — |
| Music on the watch | Yes | — |
| Storage | 64 GB | 8 GB |
| Platform | ||
| Operating system | watchOS 11 | Proprietary OS |
| Platform | watchOS | Proprietary |
| Works with | iOS | — |
| Chipset | Apple S10 | — |
